Intelligent Terminal System

TECHNICAL PARAMETERS

• Processor : 32 bit Processor
• Processor clock frequency : 50 MHZ
• Real time clock : On board battery backed RTC (32.768 KHz.)
• Memory : Capable of storing 200000 to 250000 records
• Power supply : SMPS power supply
• Input Voltage : 90V to 300V AC @ 50Hz
• A/D Converter : 24 Bit Sigma Delta type
• Load cell exciation : 8V DC, Can drive up to-12 load cells of 350 ohms each
• Protection : (A) 750mA fuse for input AC mains
• (B) Input line filter for EMI and RFI suppression
• (C) Spike suppressor for input transients
• (D) Opto-isolation of signals for high immunity from Electrical noise
• Power Consumption : 10 VA (approximately)
• Display (standard) : 240x64 Full Graphic LCD
• Keyboard port : Alphanumerical with USB compatible keyboard
• USB Port : USB Port configured for connecting Pen Drive
• Printer port : Isolated Centronics compatible printer port provided on rear panel for connecting 80-column dot matrix printer for printing of weighment records and reports.
• Serial port : RS-232 serial port is provided for computer interfacing, remote displays or modem
• Remote Display Port : Remote display port is provided to connect optional LED display (various size)
• Wi-Fi : Transmission facility to connect wireless peripherals
• Environment : Operating temperature: 0° to +65°C
• Humidity : up to 95% RH non-condensing
• Mechanical : Dimensions: 294 mm (w) x 220 mm (D) x 210mm (H)
• Weight : 2.5 kg (approx.)

FEATURES

• USB port for Keyboard / Pendrive facility
• No calibration required with use of Eagle Pre-Cal Digital Load Cell
• Memory for 200000 to 250000 records
• Facility to send SMS for weighment record (Optional)
• Facility to send Auto E-mail Data Transfer Facility (Optional)
• Field programmable 10 subtitles for ticket data entry
• Coding facility (100 codes for 4 entries)
• Field Programmable Pre-printed tickets
• Vehicle-wise data entry and report printing
• Multi level passwords for security (Dynamic or Regular)
• 240x64 Graphic LCD display for weight / weighment data
• Optional LCD with back light control for data entry
• LED display with brightness control for weight display
